Tecal ES3000 High Performance PCIe SSD Card
ES3000 Provides 800GB/1.2TB/2.4TB capacities, Full-Height Half-Length, maximum read IOPS Performance is 760K(4KB), maximum write IOPS Performance is 240K(4KB), Power-down Protection.
Beat Performance
- Small size: Full-Height Half-Length
- Large capacity: 800GB, 1.2TB, 2.4TB
- High bandwidth: PCIe 2.0 x8 interface, up to 3.2GBps bandwidth
- High IOPS: random read 760K(4KB), random write 240K(4KB)
- Low latency: 8µs
Industry-lead Reliability
- Power-down Protection to ensure data Integrity
- Embedded ECC engine and RAID5 engine combine to two-dimensional error detection/correction mechanism
- Embedded DATA Scrubbing engine prevent the data errors in advance
- Dynamic RAID algorithm used in all the channels, to share resources, and keep the reliability when the multiple chip failure
- Support TRIM & sophisticated wear algorithms, to enhance the recovery efficiency, reduce the write wear, extend service life
Easy to Maintenance
- Support online upgrade to meet the customized needs
- Integrated querying & management tool: provide querying the type/capacity/version/wear/bad block information of SSD device
- Log function: record the key events
- Support SNMP protocol for unified management system
| Model
|
ES3000
|
| Capacity
|
800GB
|
1.2TB
|
2.4TB
|
| Flash Granule
|
MLC
|
MLC
|
MLC
|
| Form Factor
|
Full-height, half-length
|
Full-height, half-length
|
Full-height, half-length
|
| Bus Interface
|
PCI Express 2.0 x8
|
PCI Express 2.0 x8
|
PCI Express 2.0 x8
|
| Read Bandwidth
|
2.2 GB/s
|
3.2 GB/s
|
3.2 GB/s
|
| Read IOPS (4KB, 100% Random)
|
570K
|
760K
|
760K
|
| Read Latency
|
49µs
|
49µs
|
49µs
|
| Write Bandwidth
|
1.2 GB/s
|
1.8 GB/s
|
2.8 GB/s
|
| Write IOPS (4KB, 100% Random)
|
120K
|
180K
|
240K
|
| Write Latency
|
8µs
|
8µs
|
8µs
|
| Mixed IOPS (4KB, R/W:7/3)
|
260K (R/W: 180K/80K)
|
400K (R/W: 280K/120K)
|
430K (R/W: 300K/130K)
|
| Power Consumption
|
25~30W
|
30~40W
|
40~60W
|
| Weight
|
300g
|
350g
|
350g
|
| Power-down Protection
|
Yes
|
Yes
|
Yes
|
| Granules Failure Protection
|
Yes
|
Yes
|
Yes
|
| Supported Trim
|
Yes
|
Yes
|
Yes
|
| Supported Operate Systems
|
MS Windows Server 2003 SP2/2008 R2 64bit;
RHEL 5/6; SLES 10/11;
CentOS 5/6; Ubuntu 10/11;
VMware ESX 4.1/ ESXi 5.0
|
| Environmental Specifications
|
| Operating temperature
|
0°C～55°C
|
| Storage temperature
|
-40°C～70°C
|
| Operating humidity
|
5% RH～85% RH
|
| Altitude
|
≤3000m
|
| International Standards
|
| US / Canada
|
FCC CFR47 Part 15 Class A
ICES-003 Class A
|
| Europe
|
EN 60950-1:2006 2nd Ed
EN 55022:2006 + A1:2007 (Class A)
EN 55024:1998 + A1:2001 + A2:2003
EN 61000-3-2:2006
EN 61000-3-3:1995 +A1:2001 +A2:2005
|
| RoHS
|
RoHS – EU Directive 2002/95/EC
|
